Nuseal Insulating Gasket

• Application
• Pipeline Flange Insulation

• Gasket Coefficient
• 0.29

• Hardness
• Shore D 85 - 90

• Inner Ring
• Phenolic / Epoxy

• Material
• Other

• Medium
• Other

• Outer Ring
• Steel / Epoxy

• Pressure Resistance
• Up to 250 bar

• Shape
• Other, Round

• Size
• Up to 48 inch

• Standard
• API 6A/6D, ANSI, DIN, BS

• Temperature Resistance
• Up to 180C

• Thickness
• 3 mm

• Vaccum Range
• Up to 1 x 10^-9 mbar

• Working Temperature
• -45C to +135C

• Height
• Custom Millimeter (mm)

• Length
• Custom Millimeter (mm)

• Material
• Graphite, Fiberglass, Metal, Other

• Shape
• Ring Gasket

• Thickness
• Custom Inch

• Weight
• Custom Kilograms (kg)

• Gasket Coefficient
• 0.22 to 0.26 (static friction coefficient)

• Hardness
• Shore D 80 5

• Inner Ring
• Epoxy coated steel or stainless steel

• Medium
• Other

• Pressure Resistance
• Class 150 to 2500 lbs

• Shape
• Other, Ring (RTJ, spiral wound, flat, full faced, raised faced)

• Size
• Suitable for pipe sizes from DN 15 to DN 1200

• Standard
• ANSI, ASME, DIN, BS, IS

• Temperature Resistance
• Up to 150C

• Thickness
• 3 mm

• Application
• Used for isolating flanges to prevent galvanic corrosion and electrical continuity in piping systems

• Gasket Coefficient
• 0.15

• Hardness
• Shore D 805

• Material
• Other

• Medium
• Other

• Outer Ring
• Neoprene faced phenolic or Stainless Steel

• Pressure Resistance
• Up to 2500 psi (Class 2500#)

• Shape
• Other, Round

• Size
• 1/2 inch to 60 inch (custom sizes available)

• Standard
• ANSI, ASME, DIN, JIS

• Temperature Resistance
• Up to 150C

• Thickness
• 3 mm

• Vaccum Range
• Full vacuum
